If youre sick of the state of social media rn, check out trinkt.co Free and available now! Grab your family/friends, share and start connecting again. 🐧πŸͺ¨
2
:🐧connect with intention trinkt.co
4
🎭 The curtain rises on the star of our show: the completed PD StepDriver prototype! 🌟 USB-C Power Delivery meets advanced motor control in one compact package. The future is here, and it's stepping strong! #ProductLaunch #InnovationInMotion
12
πŸŽ‰ Milestone alert! πŸ› οΈ Our first PD Stepper prototype is alive, merging Spark Analyzer with an A4988 stepper driver. Where USB-C power meets precision motor control! #Prototyping #ElectronicsDesign
1
1
40
This ESP32-powered device combines retro style with modern IoT features. It offers real-time sync, temperature/humidity monitoring, and more on a nostalgic LED matrix display. Use it as a clock, environmental tracker, or custom info panel. Register now -> buff.ly/4huD2gm
16
πŸŽ‰ Milestone alert! πŸ› οΈ Our first PD Stepper prototype is alive, merging Spark Analyzer with an A4988 stepper driver. Where USB-C power meets precision motor control! #Prototyping #ElectronicsDesign
29
πŸš€ Unveiling our latest innovation: PD Stepper! πŸ”Œβš‘ Combining stepper motor control with USB-C power delivery for unprecedented voltage flexibility. Get ready for a revolution in motor power management! #PDStepper #Innovation
6
πŸ€” Looking for multiple power supplies for different voltages? Not anymore! πŸ’‘ PD Stepper uses USB-C Power Delivery to simplify motor control systems. Efficiency meets simplicity! #PowerDelivery #MotorControl Check out our Spark Analyzer on @crowdsupply & @mouserelec!
6
πŸŒπŸ”¬ New project alert! Join us in shaping our Environmental Sensing project with Pi Pico. Which environmental aspects matter most to you? Air quality, sound disturbances, light levels, accelerometers, or other factors? Share your thoughts below to collaborate on innovation.
6
πŸ’‘ RetroThing is not just about looking cool - it's also about being useful. Our AHT20 temperature and humidity sensor, along with a light sensor for automatic brightness adjustment - turn RetroThing into an environmental monitor and a considerate roommate that won't blind you.
14
'It's alive! The first power-on test for RetroThing. Seeing your creation light up for the first time is truly exciting. Each LED represents hours of planning, designing, and building. What's your most exciting first power-on experience? Share your story! #RetroThing
13
The gang's all here! 🧰 We've gathered all the components for our RetroThing prototype, from the ESP32 to the LED matrices, and all the tiny resistors and capacitors in between. Each piece plays a crucial role, like a family portrait of our tech baby before assembly!
10
From pixels to PCB! πŸ–₯️ RetroThing's circuit board design in KiCad is coming together, each connection and placement crucial for our retro dream turned modern reality. It's a high-tech puzzle we're solving one step at a time. #RetroThing #PCBDesign #ElectronicsEngineering
7
The tiny ESP32 chip will make RetroThing smart with built-in WiFi, Bluetooth, and processing power for complex tasks. Share your ideas for smart features like weather updates or stock tickers! #RetroThing #ESP32 #IoT
19
Let there be light! πŸ’‘ Our first RetroThing test is glowing with potential. This 5x7 LED matrix is the key to something amazing. Four of these can work together to display time, weather & ticker info! #RetroThing #LEDMatrix #TechDevelopment
6
πŸš€ Exciting news, elektroThing fans! Introducing RetroThing - a mix of old-school LED Nixie displays with modern IoT tech. Stay tuned for this retro-future mashup. Share your ideas on what retro tech you'd like to see upgraded! #RetroThing #elektroThing #RetroTech πŸ‘‡
18
spark Analyzer is not only intelligent but also social. It utilizes Wi-Fi for long-distance communication, Bluetooth for quick local connections, and USB for direct data transfer and programming. Stay connected with your power analysis from anywhere in the world with our web app.
16
the Spark Analyzer at the output stage uses Power MOSFET for precise control, a current sense amplifier for accurate measurements, and breakout pins for easy interfacing. This stage provides the exact power required by devices, acting like a gym for electrons.
10
the ESP32-C3 microcontroller is the core of Spark Analyzer, serving as a versatile processor with Wi-Fi and Bluetooth capabilities. With 400KB of SRAM and 4MB FLASH, it handles power analysis tasks, data processing, and wireless communication efficiently.
22
the FUSB302MPX is a robust USB-C PD controller that supports USB PD 3.0 and PPS, handling up to 100W. It effectively manages voltage & current, enabling Spark Analyzer to work with various USB-C PD & PPS adapters. The 'F' stands for 'Fairchild', the original manufacturer.
21
