Victorian Elegance, Powered by the Future.
This Tesla Energy installation by
@AHCDMV is incredible:
• Total PV Capacity: 12.312 kW DC
• Total AC Capacity: 11.4 kW combined from two
Tesla inverters
• STC Rating: 12,312 W
• PTC Rating: 11,184 W
The system is built from 171 Tesla SR72T2 solar tiles (72 watts each) mounted across multiple roof planes.
Two Tesla Powerwall 2 units:
Each: 5 kW output, combined 26.3 kWh storage
Backup Gateway 2:
• Controls automatic outage transition
• Separates backed-up loads from non-backed-up loads
• 200A Backup Loads Panel for general circuits
• 200A Non-Backup Panel for remaining household loads
• This layout gives the home full-house backup coverage design flexibility.
