20 Aug 2021
Project Hammer design reveal. Very happy with how it turned out.
2
35
10 Jun 2021
X axis drive module cooling PCB with direct connection to stepper motor. This is for an enclosed printer where temps can affect stepper motor performance.
2
1
24
9 Jun 2021
Not done yet but too good not to share. The most overkill hobby spindle. That's right, integrated fld/mst cooling and purge air. Still missing a key feature, waiting on PCB 😉. This little CNC mill is going to be badass!
3
5
63
9 Jun 2021
Glad that's over! Post heat fit up. The body has been bored slightly undersized it is then heated and slid over the spindle cartridge making for a permanent fit that is uniformly even.
1
12
19 May 2021
Project Hyperion (3d printer). X axis drive module designed for extremely long service life. Quick mock up assembly minus idlers. Can you spot the features that aid in durability?
11
5
48
13 Apr 2021
Hope I don't f*ck this up. Time to sort through a bajillion parameters.
1
10
11 Apr 2021
Them: Just keep it simple. Don't get carried away.
Me: Like this..
3
1
41
7 Apr 2021
Power section with custom AC distro PCB. Project Hyperion.
15
27 Mar 2021
Throwback to the first 3D printer I designed and built. All of the 3D printers I have produced after can trace their printed parts lineage back to this printer. Because this printer was my first, all parts had to be machined. 400mm cubic coreXY
6
3
73
27 Mar 2021
The CAD model is on grabcad for those that want to poke around. grabcad.com/library/large-co…
1
3 Mar 2021
These Chinese companies will go through the hassle to make make 15 mm wide GT2 belts and drive pulleys but they don't make 15 mm wide GT2 idlers. WTF!!?!?
5
9
16 Feb 2021
When you have one of those last-minute prints that just turns out so good you got to show it off.
2
4
53
12 Feb 2021
Doing a little experiment today feeling extrusion with sand to help combat resonance of my printer builds. 3D printed plugs with o-rings make a nice tight fit. Finally super glue helps ensure the plugs never move and keep the sand compressed.
4
3
35
6 Feb 2021
I've become way too obsessed with this new project.
2
