The NucleoTNC is an open implementation of our commercial product, the TNC3, designed to encourage experimentation and learning in amateur radio, electronics, digital signal processing and software engineering.
github.com/mobilinkd/NucleoT…
6
12
39
I am really excited to see the TNC4's latent M17 features on display. See Jeff, AE5ME, demo of the MSEVEN app, created by Greg, W5GGW, using a TNC4 for M17 voice over the air.
youtube.com/watch?v=fFFd1BZ4…
152
aprs.fi is now available for Android (v11 )! All the features of the iPhone app and a few more. Buy the app and get the web site for free! Do read the application description before purchasing. play.google.com/store/apps/d… #aprs #hamradio
3
18
58
2,469
makerworld.com/en/models/240…
Thom, W8TAM, has created a mod for the TK-x90 radios to use Anderson Powerpole connectors directly for the power connection.
1
7
223
We now have TNC cables designed for the Yaesu FTM mobile radios. We also have the MiniDIN-6 adapter (CT-164 equivalent) and a MiniDIN-10 bare cable (CT-167 equivalent).
store.mobilinkd.com/collecti…
1
3
336
Our redesigned TNC cable for ICOM radios are a good fit for the deeper ID-50/51/52 socket.
9
459
You can now also find us at bsky.app/profile/mobilinkd.b…
1
174
Mobilinkd -- Find us @Mobilinkd@mastodon.radio retweeted
11 Nov 2024
My night is Crazy Full working on my @Mobilinkd TNc for some #APRS. Testing more #clockworkpi #uconsole-kit-rpi-cm4-lite Stuff!!
3
16
133
7,255
TNC4 firmware version 2.5.14 has been released and the User Guide has been updated. The TNC will indicate when its audio input is being overdriven. PTT lockup on iOS when 2 or more apps are attached is fixed. 9600 baud modulator and #M17 demod is improved.
mobilinkd.com/downloads/?dl_…
1
7
401
github.com/mobilinkd/NucleoT…
These changes are now released. As part of the ongoing repo re-org, the NucleoTNC firmware now has its own Github repository. The fine frequency adjustments to the ADC and DAC timers works pretty well.
2
444
While we love selling our aluminum NucleoTNC enclosures, the fact that there are two distinct 3D-printable NucleoTNC enclosures on Thingiverse is so heart-warming to see. #OSHW
A huge "thank you" to all those that contribute to #opensource #hamradio.
thingiverse.com/search?q=nuc…
2
317
The #hamradio NucleoTNC repository is being split into 3 separate repos. The PCB, spacer, and enclosure KiCAD files are now #OSHW licensed under CERN-OHL-S and available here: github.com/mobilinkd/NucleoT…
3
303
If you have a Rev B NucleoTNC board and want to use it for M-17 data, swapping out C1 & C2 for 22uF 16V caps is recommended. This is one of the changes on the Rev C board & schematic.
6
330
Easy modification to an #STM32 Nucleo32 board to allow SWO debugging while preserving LD3 functionality. This allows using SWO when debugging the NucleoTNC (mobilinkd.com/2019/06/24/nuc…). #hamradio
3
384
Here is an update for the special #UVK5 firmware I've been working on supporting #hamradio digital modes (flat response) to fix an issue with frequency drift caused by varying DC bias on the BK4819's MIC line.
github.com/mobilinkd/uv-k5-f…
1
7
1,718
UV-K6 mods for digital modes -- both hardware and firmware -- are now documented here: github.com/mobilinkd/uv-k6-d…
5
16
3,291
Custom firmware (egzumer fork) for Quansheng #uvk5 #uvk6 with support for digital modulation mode is available here: github.com/mobilinkd/uv-k5-f…
This provides a flat response in TX and RX. A few small hardware mods are needed. These will be documented in detail soon.
2
9
1,431
Mobilinkd -- Find us @Mobilinkd@mastodon.radio retweeted
Eyes wide open -- Quansheng #uvk6 (AKA #UVK5) 9600 baud GFSK reception. Small HW modifications, and egzumer firmware modified for digital modulation/demodulation. #hamradio
ALT Eye diagram of GFSK baseband reception from Quansheng UV-K6.
