Generated from Claud with no prior context except the seed:
"Hi Claude I want to serve search results from a Github codebase using vector search over the chunks of the code base. Tell me some high level software architecture designs for this description:"
And had a couple of phases of conversation. And it managed to produce this. Very based Claude, very based
/vector-search-github/
โโโ data_ingestion/
โ โโโ github_api_client.py
โ โ class GitHubAuth:
โ โ - token: str
โ โ __init__(token: str)
โ โ get_headers() -> dict
โ โ
โ โ class GitHubRepo:
โ โ - name: str
โ โ - api_url: str
โ โ __init__(name: str, api_url: str)
โ โ get_file_list() -> list[str]
โ โ
โ โ class GitHubClient:
โ โ - auth: GitHubAuth
โ โ __init__(auth: GitHubAuth)
โ โ fetch_repository(repo: GitHubRepo) -> dict
โ โ get_file_content(repo: GitHubRepo, file_path: str) -> str
โ โ get_commit_history(repo: GitHubRepo, file_path: str) -> list
โ โ
โ โโโ code_chunker.py
โ โ class ChunkConfig:
โ โ - chunk_size: int
โ โ - overlap: int
โ โ __init__(chunk_size: int, overlap: int)
โ โ
โ โ class Chunk:
โ โ - content: str
โ โ - start_line: int
โ โ - end_line: int
โ โ __init__(content: str, start_line: int, end_line: int)
โ โ
โ โ class CodeChunker:
โ โ - config: ChunkConfig
โ โ __init__(config: ChunkConfig)
โ โ chunk_code(code_string: str) -> list[Chunk]
โ โ process_file(file_content: str) -> list[Chunk]
โ โ
โ โโโ text_embedding.py
โ โ class EmbeddingModel:
โ โ - name: str
โ โ - dimension: int
โ โ __init__(name: str, dimension: int)
โ โ load() -> None
โ โ
โ โ class TextEmbedder:
โ โ - model: EmbeddingModel
โ โ __init__(model: EmbeddingModel)
โ โ embed_text(text: str) -> np.ndarray
โ โ embed_chunks(chunks: list[Chunk]) -> list[np.ndarray]
โ โ
โ โ class SimilarityCalculator:
โ โ compute_similarity(vec1: np.ndarray, vec2: np.ndarray) -> float
โ โ
โ โโโ code_analyzer.py
โ โ class CodeStructure:
โ โ - functions: list[str]
โ โ - classes: list[str]
โ โ __init__(functions: list[str], classes: list[str])
โ โ
โ โ class ComplexityMetrics:
โ โ - cyclomatic_complexity: int
โ โ - cognitive_complexity: int
โ โ __init__(cyclomatic_complexity: int, cognitive_complexity: int)
โ โ
โ โ class CodeAnalyzer:
โ โ extract_structure(code: str) -> CodeStructure
โ โ analyze_complexity(code: str) -> ComplexityMetrics
โ โ detect_language(code: str) -> str
โโโ vector_database/
โ โโโ vector_store.py
โ โ class VectorEntry:
โ โ - id: str
โ โ - vector: np.ndarray
โ โ - metadata: dict
โ โ __init__(id: str, vector: np.ndarray, metadata: dict)
โ โ
โ โ class VectorStore:
โ โ - database: DatabaseManager
โ โ __init__(database: DatabaseManager)
โ โ insert_vector(entry: VectorEntry) -> None
โ โ search_similar(query_vector: np.ndarray, top_k: int) -> list[VectorEntry]
โ โ delete_vector(vector_id: str) -> None
โ โ update_vector(vector_id: str, new_entry: VectorEntry) -> None
โ โ
โ โโโ
indexing.py
โ โ class IndexConfig:
โ โ - algorithm: str
โ โ - parameters: dict
โ โ __init__(algorithm: str, parameters: dict)
โ โ
โ โ class VectorIndex:
โ โ - config: IndexConfig
โ โ - index: Any # Placeholder for the actual index structure
โ โ __init__(config: IndexConfig)
โ โ build_index(vectors: list[np.ndarray]) -> None
โ โ query(query_vector: np.ndarray, num_results: int) -> list[int]
โ โ add_to_index(vector: np.ndarray, id: int) -> None
โ โ remove_from_index(id: int) -> None
โ โ
โ โโโ database_manager.py
โ โ class DatabaseConfig:
โ โ - url: str
โ โ - max_connections: int
โ โ __init__(url: str, max_connections: int)
โ โ
โ โ class DatabaseManager:
โ โ - config: DatabaseConfig
โ โ - connection: Any # Placeholder for the actual database connection
โ โ __init__(config: DatabaseConfig)
โ โ create_tables() -> None
โ โ execute_query(query: str, params: tuple) -> None
โ โ fetch_all(query: str, params: tuple) -> list
โ โ close_connection() -> None
โโโ search_api/
โ โโโ query_handler.py
โ โ class Query:
โ โ - text: str
โ โ - filters: dict
โ โ __init__(text: str, filters: dict)
โ โ
โ โ class SearchResult:
โ โ - content: str
โ โ - similarity: float
โ โ - metadata: dict
โ โ __init__(content: str, similarity: float, metadata: dict)
โ โ
โ โ class QueryHandler:
โ โ - vector_store: VectorStore
โ โ - text_embedder: TextEmbedder
โ โ __init__(vector_store: VectorStore, text_embedder: TextEmbedder)
โ โ process_query(query: Query) -> list[SearchResult]
โ โ format_results(search_results: list[SearchResult]) -> list[dict]
โ โ
โ โโโ vector_converter.py
โ โ class VectorConverter:
โ โ - text_embedder: TextEmbedder
โ โ __init__(text_embedder: TextEmbedder)
โ โ text_to_vector(text: str) -> np.ndarray
โ โ
โ โ class VectorCompressor:
โ โ - compression_method: str
โ โ __init__(compression_method: str)
โ โ compress_vector(vector: np.ndarray) -> np.ndarray
โ โ decompress_vector(compressed_vector: np.ndarray) -> np.ndarray
โ โ
โ โโโ similarity_search.py
โ โ class SearchConfig:
โ โ - top_k: int
โ โ - similarity_threshold: float
โ โ __init__(top_k: int, similarity_threshold: float)
โ โ
โ โ class SimilaritySearch:
โ โ - vector_store: VectorStore
โ โ - vector_index: VectorIndex
โ โ - config: SearchConfig
โ โ __init__(vector_store: VectorStore, vector_index: VectorIndex, config: SearchConfig)
โ โ search(query_vector: np.ndarray) -> list[SearchResult]
โ โ range_search(query_vector: np.ndarray, radius: float) -> list[SearchResult]
โ โ
โ โโโ search_optimizer.py
โ โ class QueryCache:
โ โ - cache: dict
โ โ - max_size: int
โ โ __init__(max_size: int)
โ โ add(query: str, results: list[SearchResult]) -> None
โ โ get(query: str) -> list[SearchResult]
โ โ
โ โ class SearchOptimizer:
โ โ - similarity_search: SimilaritySearch
โ โ - query_cache: QueryCache
โ โ __init__(similarity_search: SimilaritySearch, query_cache: QueryCache)
โ โ optimize_query(query: str) -> str
โ โ cache_frequent_queries(query_history: list[str]) -> None
โ โ suggest_related_queries(query: str) -> list[str]
โโโ web_interface/
โ โโโ
app.py
โ โ class FlaskApp:
โ โ - app: Flask
โ โ - query_handler: QueryHandler
โ โ __init__(query_handler: QueryHandler)
โ โ index() -> str
โ โ search() -> str
โ โ advanced_search() -> str
โ โ api_search() -> dict
โโโ background_jobs/
โ โโโ update_codebase.py
โ โ class UpdateTask:
โ โ - repo: GitHubRepo
โ โ - last_update: datetime
โ โ __init__(repo: GitHubRepo)
โ โ
โ โ class CodebaseUpdater:
โ โ - github_client: GitHubClient
โ โ - vector_store: VectorStore
โ โ - tasks: list[UpdateTask]
โ โ __init__(github_client: GitHubClient, vector_store: VectorStore)
โ โ check_for_updates() -> list[str]
โ โ process_updates(updates: list[str]) -> None
โ โ
โ โโโ refresh_vector_db.py
โ โ class RefreshTask:
โ โ - chunk: Chunk
โ โ - last_refresh: datetime
โ โ __init__(chunk: Chunk)
โ โ
โ โ class VectorDBRefresher:
โ โ - vector_store: VectorStore
โ โ - code_chunker: CodeChunker
โ โ - text_embedder: TextEmbedder
โ โ - tasks: list[RefreshTask]
โ โ __init__(vector_store: VectorStore, code_chunker: CodeChunker, text_embedder: TextEmbedder)
โ โ refresh_database() -> None
โ โ process_chunk(chunk: Chunk) -> None
โ โ
โ โโโ job_scheduler.py
โ โ class Job:
โ โ - id: str
โ โ - func: callable
โ โ - trigger: str
โ โ - kwargs: dict
โ โ __init__(id: str, func: callable, trigger: str, **kwargs)
โ โ
โ โ class JobScheduler:
โ โ - jobs: list[Job]
โ โ __init__()
โ โ add_job(job: Job) -> None
โ โ remove_job(job_id: str) -> None
โ โ start() -> None
โ โ shutdown() -> None
โโโ config/
โ โโโ
settings.py
โ โโโ logging_config.py
โ โ class LogConfig:
โ โ - level: str
โ โ - format: str
โ โ - file: str
โ โ __init__(level: str, format: str, file: str)
โ โ
โ โ setup_logging(config: LogConfig) -> None
โ โ get_logger(name: str) -> Logger
โโโ utils/
โ โโโ performance_monitor.py
โ โ class Timer:
โ โ - start_time: float
โ โ - end_time: float
โ โ start() -> None
โ โ stop() -> float
โ โ
โ โ class PerformanceMonitor:
โ โ - timers: dict[str, Timer]
โ โ - memory_usage: list[float]
โ โ start_timer(operation: str) -> None
โ โ stop_timer(operation: str) -> float
โ โ log_memory_usage() -> None
โ โ generate_report() -> dict
โ โ
โ โโโ error_handler.py
โ โ class ErrorContext:
โ โ - module: str
โ โ - function: str
โ โ - parameters: dict
โ โ __init__(module: str, function: str, parameters: dict)
โ โ
โ โ class ErrorHandler:
โ โ - logger: Logger
โ โ __init__(logger: Logger)
โ โ handle_error(error: Exception, context: ErrorContext) -> None
โ โ log_error(error: Exception, context: ErrorContext) -> None
โ โ notify_admin(error: Exception, context: ErrorContext) -> None
โโโ tests/
โ โโโ test_github_api_client.py
โ โโโ test_code_chunker.py
โ โโโ test_text_embedding.py
โ โโโ test_vector_store.py
โ โโโ test_query_handler.py
โ โโโ test_similarity_search.py
โ โโโ test_web_interface.py
โโโ
main.py
initialize_components() -> tuple
setup_background_jobs(job_scheduler: JobScheduler) -> None
main() -> None
