ALT ✔️ The CPO-PC500 is a next generation plant controller of the Comfort Point Open (CPO) Plant Controller family powered with a quad-core processor. ✔️ This an Ethernet-based, freely programmable, and native BACnet Building Controller (B-BC). ✔️ The CPO-PC500 is designed for a wide variety of complex applications. ✔️ This device features three RS485 channels, two Ethernet ports for BACnet IP devices, an RJ11 interface for HMI device, Touch flakes to connect with multiple IOs in series, and two USB Type-C interfaces to connect with PC/laptop for serial communication. ✔️ Built-in advanced diagnostics software facilitating troubleshooting for IP and MSTP devices. ✔️ Programmed and Serviced using the Honeywell CPO Studio Tool Suite.

ALT 🔷Siemens HVAC equipment automation engineering tool Climatix Project Studio. 🔷Climatix Project Studio Automation (in short, Climatix Automation) is the equipment automation programming tool for Climatix controllers. 🔷This is the second generation of Climatix programming tools. 🔷It features efficient engineering, team engineering, and multiple programming language support. It offers the following functionalities: ✔️Equipment control logic programming with IEC 61131-3 standard languages. ✔️Libraries of automation object and function blocks for HVAC equipment control. ✔️Automated test of control logics with test framework. ✔️Support in continuous integration test to facilitate fast team development. ✔️Integration of MATLAB SIMULINK code as function blocks running on Climatix controllers. ✔️Compatible with the first generation of Climatix programming and commissioning tools SAPRO, SCOPE, and SCOPE light. A tool for migrating SAPRO projects into Climatix Automation is provided.

ALT ➤ Selecting the right damper actuator can impact system reliability, performance, and operational efficiency. This technical comparison of Belimo GM24A-SR and GM24-SR.1B reviews important specifications including control features, operating characteristics, and HVAC application differences. ➤ This post is designed for engineers, HVAC professionals, system integrators, and building automation specialists looking for practical insights during product selection and project planning.

ALT ➤The modu600-LO operating device can be used to operate the modulo 6 I/O modules locally and to display their input and output signals. The module is hot-pluggable. It reads and accepts the configuration of the I/O module to which it is connected. ✔️Part of the SAUTER modulo 6 system family, ✔️Pluggable element for direct operation and visualisation of displays for the modu6** I/O modules, ✔️Automatic detection of the current I/O module configuration, ✔️Display of values and statuses of the inputs and outputs on an LCD colour display, ✔️Detailed display of the individual inputs and outputs including labelling, type, status and graphics, ✔️Simple 4-button operation, ✔️LED indicator of I/O module modu6**-IO, ✔️Local priority operation, ✔️Ready for use without parameterising,

ALT 💡 Key Technical Highlights: ✔️ Part of the SAUTER modulo 6 system family, ✔️ Plug-in element for extending the modu660‑AS and modu680‑AS automation stations and the modu612‑LC IP coupler, ✔️ Activation with a standard signal (0(2) to 10 V, 0(4) to 20 mA) in operational systems, such as HVAC engineering, ✔️ Receiving digital inputs (alarm/status or pulse counter) and analogue inputs (Ni/Pt1000, U, I, R, pot.) in operational systems, ✔️ Four universal inputs, four analogue outputs and four digital outputs, ✔️ Power supply from modu6**-AS automation station, modu612‑LC IP coupler or modu601‑LC supply module, ✔️ Can be equipped locally with a modu600‑LO operating and indicating unit,

ALT 💡 Key Technical Highlights: • Part of the SAUTER modulo 6 system family, • Modular automation station, expandable with I/O modules and communication modules, • Regulation, control, monitoring and optimisation of operational systems in HVAC engineering, • Locally expandable with up to 24 modules via the SAUTER Extension Bus, • Can be locally equipped with ecoLink I/O modules and ASV actuators via SLC interface, • RS-485 interface for field bus integration (Modbus/RTU/ASCII) • Four RJ45 connections for two separate IP networks (OT/IT; Operational/Information Technology). • Integrated web server for local commissioning, visualisation and operation • User administration for identification, authentication and access control • Encryption of communication with TLS • Bluetooth interface for mobile commissioning and maintenance • Programming/parameterisation via PC using CASE Suite (based on IEC 61131-3)

ALT Explore the technical specifications of the YASKAWA A1000 AC Drive featuring advanced motor control, energy efficiency, high torque performance & industrial reliability for automation systems. Key Technical Highlights: ✔ Advanced Vector Control ✔ High Starting Torque Performance ✔ Flexible Communication Protocol Support ✔ Compact & Robust Design ✔ Energy Optimization Features ✔ Industrial-Grade Protection Functions Common Applications Include: 🔹 HVAC Systems 🔹 Pumps & Fans 🔹 Conveyors 🔹 Compressors 🔹 Manufacturing Plants 🔹 Process Automation This drive solution supports improved operational efficiency, reduced energy consumption, and stable motor performance in demanding industrial conditions.

ALT Schneider Electric SpaceLogic Automation Server AS-B 36 I/O points Plant Room Controller⚠️ ✔️ The AS-B server is a powerful device with built-in power supply and I/O, which makes it suitable for control applications at the plant room level of a BMS in all sizes of buildings. ✔️ The AS-B server can act as a standalone server or controller using its built-in I/O and also monitor and manage field bus devices. ✔️ In a small installation, the embedded AS-B server acts as a standalone server or controller, mounted in a small footprint. ✔️ In medium and large installations, functionality is distributed over multiple automation servers that communicate over TCP/IP. ✔️ At the core of an EcoStruxure BMS is an automation server, such as the SpaceLogic AS-B server. ✔️ The AS-B server performs key functionality, such as control logic, trend logging, and alarm supervision, provides built-in I/O, and supports communication and connectivity to the field buses.

ALT The IQ4E controller has 10 universal inputs and 6 analogue voltage outputs and is expandable up to 192 points (depending on the controller variant) by adding I/O modules. This flexibility makes it suitable for a broad range of applications. 🔹I/O bus length up to 300 m (328 yards), 🔹Ethernet 10/100 Mbps main network with TCP/IP protocol, 🔹Trend current loop LAN option, 🔹Embedded XML Web Services as standard, 🔹BACnet over IP (certified BACnet Building Controller (B-BC)), 🔹Wallbus for connection of room displays, 🔹RS232 and USB local supervisor/engineering ports, 🔹Automatic time synchronisation and daylight saving via SNTP, 🔹DIN rail mounting, DIN 19 size 2 standard enclosure, 🔹Optional interfacing to Serial/IP MODBUS, and M-Bus devices. 🔹230 Vac, 24 Vac or 48 Vdc input power supply options,

ALT ✔️ The AS-B server is a powerful device with built-in power supply and I/O, which makes it suitable for control applications at the plant room level of a BMS in all sizes of buildings. ✔️ The AS-B server can act as a standalone server or controller using its built-in I/O and also monitor and manage field bus devices. ✔️ In a small installation, the embedded AS-B server acts as a standalone server or controller, mounted in a small footprint. ✔️ In medium and large installations, functionality is distributed over multiple automation servers that communicate over TCP/IP. ✔️ At the core of an EcoStruxure BMS is an automation server, such as the SpaceLogic AS-B server. ✔️ The AS-B server performs key functionality, such as control logic, trend logging, and alarm supervision, provides built-in I/O, and supports communication and connectivity to the field buses.

ALT Siemens Climatix products are designed for use in heating, ventilation, air conditioning and refrigeration machines and provide a broad range of control and monitoring functions. • Freely programmable modular controllers • 21, 27 and 29 physical inputs / outputs per controller • Integrated stepper motor outputs with failsafe behavior (UPS) • Integrated local or remote HMI • Standard USB service connection for tool access • Ethernet port for Modbus, BACnet, OPC UA, SNMP, servicing and Climatix IC • SD card interface for applications, firmware update, and archiving • Physical input/output extension using extension modules • RS-485 (galvanically separated) interface for Modbus and BACnet • RS-485 interface for Modbus • Process bus for networking of Siemens devices • Additional connectivity with BACnet IP, BACnet MS/TP, Modbus, M-bus and LON communication modules • BACnet profile (B-ASC) Application Specific Controller is supported

ALT Siemens Climatix C600 controllers for heating, ventilation, air conditioning and refrigeration equipment. 💡 Highlight: • Freely programmable modular controllers • 21, 27 and 29 physical inputs / outputs per controller • Integrated stepper motor outputs with failsafe behavior (UPS) • Integrated local or remote HMI • Standard USB service connection for tool access • Ethernet port for Modbus, BACnet, OPC UA, SNMP, servicing and Climatix IC • SD card interface for applications, firmware update, and archiving • Physical input/output extension using extension modules • RS-485 (galvanically separated) interface for Modbus and BACnet • RS-485 interface for Modbus • Process bus for networking of Siemens devices • Additional connectivity with BACnet IP, BACnet MS/TP, Modbus, M-bus and LON communication modules • BACnet profile (B-ASC) Application Specific Controller is supported

ALT Siemens Climatix C600 controllers for heating, ventilation, air conditioning and refrigeration equipment. • Freely programmable modular controllers • 21, 27 and 29 physical inputs / outputs per controller • Integrated stepper motor outputs with failsafe behavior (UPS) • Integrated local or remote HMI • Standard USB service connection for tool access • Ethernet port for Modbus, BACnet, OPC UA, SNMP, servicing and Climatix IC • SD card interface for applications, firmware update, and archiving • Physical input/output extension using extension modules • RS-485 (galvanically separated) interface for Modbus and BACnet • RS-485 interface for Modbus • Process bus for networking of Siemens devices • Additional connectivity with BACnet IP, BACnet MS/TP, Modbus, M-bus and LON communication modules • BACnet profile (B-ASC) Application Specific Controller is supported

ALT 💡 Highlight: • Freely programmable modular controllers • 21, 27 and 29 physical inputs / outputs per controller • Integrated stepper motor outputs with failsafe behavior (UPS) • Integrated local or remote HMI • Standard USB service connection for tool access • Ethernet port for Modbus, BACnet, OPC UA, SNMP, servicing and Climatix IC • SD card interface for applications, firmware update, and archiving • Physical input/output extension using extension modules • RS-485 (galvanically separated) interface for Modbus and BACnet • RS-485 interface for Modbus • Process bus for networking of Siemens devices • Additional connectivity with BACnet IP, BACnet MS/TP, Modbus, M-bus and LON communication modules • BACnet profile (B-ASC) Application Specific Controller is supported
