27 Jun 2025
in the next version of tscircuit, assembly diagrams get an upgrade!
1
6
862
30 Sep 2024
tscircuit is one of the best projects to contribute to for Hacktoberfest!! We have hundreds of open issues and video tutorials to get started, read more below! (and win a hat!?)
2
1
10
1,771
14 Jun 2024
In the next version of tscircuit, you can add trace hints to pads directly from the preview window- much better š
3
838
I've been developing an AI text-to-footprint tool for @tscircuit, you can now play with the technical preview online: text-to-footprint.tscircuit.ā¦
1
2
11
1,066
1 May 2024
coming soon, a new way to edit your PCB layout!
(we're caving in- dragging components a lot of times is easier than describing a layout, don't worry all movements turn into code!)
604
21 Apr 2024
In the next version of @tscircuit, PCB trace errors are visible inside the PCB preview!
626
19 Apr 2024
In the next version of tscircuit, you can use the "d" key to quickly find distances on your PCB layout
1
373
12 Apr 2024
You can now export Gerbers directly from `tsci dev`'s preview window!
1
280
10 Apr 2024
Prototype of Gerber export is now working! This is step 1 of the ~4 step master plan:
1. Gerber export ā
2. drl file export
3. probably some other export format I'm forgetting
4. order first fully assembly tscircuit PCB!
172
8 Apr 2024
Hovering over overlapping pads will now show every pad selector in a readable way
2
156
