Pure mechanical poetry. This cutaway of a classic Pratt & Whitney R-985 gives a perfect view inside a 9-cylinder radial aircraft engine. Seeing the pistons fire in a perfect circular sequence to deliver smooth rotary motion through that central crankshaft is highly satisfying.
The master rod system handling all that synchronized power is an absolute masterclass in vintage engineering.
