19 Nov 2025
AutoBlock T-joint makes complex T-junction meshing effortless from turbine cooling passages to piping branches. Generate clean, low-skew topology automatically and speed up your CFD workflow.
#GridPro #CFD #Meshing #TJoint #GridProV10
2
106
13 Nov 2025
Structured multiblock mesh & CFD solution of the CassiniβHuygens Space Probe generated using GridPro.
High-quality, topology-based meshing for complex spacecraft geometry enabling accurate aero & thermal simulations. π
#GridPro #CFD #Aerospace #CassiniHuygens #StructuredMesh
1
3
179
10 Nov 2025
Structured multi-block mesh for a CHT turbine blade with cooling holes, passages & ribs generated using GridPro.
Its Hole-Topology Algorithm auto-builds blocks around complex hole patterns.
π hubs.ly/Q03SmXpm0
#CFD #CHT #GridPro #Meshing #Turbomachinery
2
109
22 Oct 2025
Join Our Webinar: Simulation-Driven Optimization with CAESES, GridPro & Ansys CFX (by Flowthermolab)
Date: Oct 29, 2025.
Time: 10:00 A.M.EDT; 4:00 P.M. CET
Speakers: Samuel from @GridPromesh Mattia from @CAESES, Rahul from @flowthermolab
Register here: bit.ly/4ndA0yH
2
127
9 Oct 2025
Meshing wire-wrapped nuclear fuel rods isnβt easy but precision matters for reactor safety. βοΈ
Using #GridPro, CEA achieved fully structured, flow-aligned meshes for accurate CFD of sodium-cooled reactors.
Read more π
π bit.ly/4mUg1VC
1
2
74
6 Oct 2025
π°οΈ Control Surface Analysis β Grid Fin
Structured multiblock mesh captures separation, shocks, boundary layers & wakes for precise CFD.
GridPro ensures orthogonality, smooth transitions & high-quality grids for extreme aero conditions.
#CFD #SpaceTech #GridPro #Aerospace
5
155
29 Sep 2025
π Secondary Flow Analysis β Serpentine S-Duct
Structured multiblock mesh captures secondary flows, separation & vortex interactions for accurate turbulence & pressure predictions.
Powered by GridPro mesh smoothing for refined, distortion-free cells.
1
2
127
23 Sep 2025
Automating grid generation for reentry simulations π
With GridPro, structured shock-fitted grids capture shocks, wakes & shear layers with precision. From Viking to Orion, automation drives accuracy & speed.
π hubs.ly/Q03KzBP60
#CFD #Aerospace #Hypersonics
4
397
22 Sep 2025
π Geometry Optimization β Generic Drone
Multiple geometries tested β optimized performance.
With GridPro, high-quality meshes are auto-generated & integrated with CAD optimization tools for efficient CFD-driven design.
#CFD #DroneDesign #GridPro #Aerospace
1
3
124
18 Sep 2025
NEW: GridPro just got brighter! π‘
Weβve enhanced our modules with LED indication β a sleeker, more discreet alternative to neon.
β¨ Modern look
πͺ Same trusted durability
π¨ Finishes from Antique Brass to Black Nickel
Explore the update π scolmore.com/article/click-sβ¦
1
2
96
15 Sep 2025
Hexahedral structured mesh for a fighter aircraft intake π
Captures boundary layers, separation & recirculation for accurate prediction of pressure recovery, flow uniformity & aerodynamic performance.
Powered by GridPro for smooth, orthogonal grids.
#CFD #Aerospace #GridPro
5
225
8 Sep 2025
Structured multiblock mesh around a wind turbine blade using GridPro βοΈ
Refined with the Nesting Tool β capturing tip vortices & boundary layers with high accuracy while keeping grids efficient. π¬οΈβ‘
#CFD #Meshing #GridPro #WindEnergy #Turbomachinery
7
296
4 Sep 2025
π From concept to grid in a day!
Structured mesh of a two-stage-to-orbit launcher using NASA-inspired GridPro.
βοΈ Smooth, orthogonal meshes
βοΈ Reusable topology templates
βοΈ Faster design iterations across aerospace & beyond
#CFD #Aerospace #MeshGeneration #NASA
1
8
366
3 Sep 2025
A fully one-one connected, hexahedral #mesh on a #rocket with a ribbed #nozzle, created on #GridPro!
#CAE #CFD #Meshing #MeshingMonday #FluidDynamics #Simulation
1
9
365
2 Sep 2025
In this #TutorialTuesday video, we will be showing you how to mesh a slab delta wing test model, and create a #mesh which is able to accurately capture the shock and surrounding flow physics.
bit.ly/4p1GyCz
#GridPro #CAE #CFD #StructuredMesh #Meshing #Simulation
2
170
29 Aug 2025
π― Fluidic Thrust Vector Control - Nozzle with Jet
Accurate nozzle deflection starts with the mesh.
With GridPro:
πΉ Captures flow separation, vortices & jet interaction
πΉ Refined mesh in throat & injector regions
πΉ y < 0.5 for precise jet & boundary layer predictions
1
2
31
734
26 Aug 2025
Learn how to merge the multi-block meshes in #GridPro.
This is useful in cases where there is an upper limit in the number of blocks the #CFD solver can use, or also in cases where the solver has it's own partitioning #algorithm.
hubs.ly/Q03FtPkz0
1
3
151
20 Aug 2025
GridPro excels at capturing complex geometry and flow physics! π
From robust topology generation to precise surface conformity, GridPro ensures accurate CFD simulations for challenging designs like the Zircon missile.
#gridpro #CFD #CAD #CAE #aerospace
1
6
250
19 Aug 2025
This #TutorialTuesday, we look at how we can create a high quality Higher order #mesh in GridPro by setting the right density for each block
π₯ Watch the full tutorial here: hubs.ly/Q03DlV3G0
#computationalfluiddynamics #cfd #structured #higherorder
5
172
18 Aug 2025
π High-resolution multi-block mesh of a Space Shuttle nozzle, capturing intricate rib details with #GridPro.
Precision meshing = accurate CFD = better aerospace designs.
#CFD #AerospaceEngineering #MeshGeneration #StructuredMesh #SpaceShuttle
8
284
