ALT In-floor heating control system using the EQSP32 industrial IoT micro-PLC integrated with Home Assistant, showing underfloor heating pipes beneath the floor, a mobile Home Assistant dashboard with multi-zone temperature control, and the EQSP32 DIN-rail controller used for industrial and smart home automation, MQTT-based building automation, and underfloor heating control in residential and commercial installations.

ALT Diagram titled “DMX512 – DMX Universe & Bus Model” showing an EQSP32 used as a DMX controller connected over an RS485 DMX bus to multiple DMX lighting devices, each assigned a sequential channel range within a single DMX universe.

ALT Informational slide explaining the DMX512 universe concept, stating that one universe is a single RS485 data stream supporting up to 512 sequential channels, with all devices receiving the full frame and responding only to their configured start address.

ALT Graphic showing an EQSP32 industrial IoT controller used as a DMX512 controller, displayed alongside stage lighting fixtures over a concert crowd background, with the text “DMX512 Integration – Using EQSP32 as a DMX controller.”

ALT Branded Erqos Technologies graphic with the tagline “Automation, made easy.” displayed above an EQSP32 industrial IoT micro-PLC mounted on a DIN rail, shown on a clean white background.

ALT Image showing three EQSP32 expansion modules displayed side by side on a light technical blueprint background, representing downloadable 3D CAD models for mechanical design and DIN-rail planning. The modules include the EQXPH01 pH meter expansion module, the EQXAI08 8-channel analog input expansion module, and the EQX2G quad-band GSM/GPRS cellular expansion module. Each module is housed in a compact DIN-rail enclosure with front-facing connectors and status indicators. The image highlights the availability of EQSP32 expansion module 3D models to support system integration, DIN-rail layout planning, enclosure design, and mechanical installation in industrial automation and IoT applications.

ALT Image showing the EQXAI08 analog input expansion module mounted in a DIN-rail enclosure next to a 4–20 mA industrial sensor. The module front panel is labeled “EQXAI08 8 Ch Analog In” and illustrates support for 8 analog input channels used with the EQSP32 IoT Logic Controller.

ALT Diagram highlighting key features of the EQXAI08 analog input expansion module for the EQSP32 IoT Logic Controller, including 8 mixed analog inputs configurable per channel for 0–10 V or 4–20 mA, up to 14-bit effective resolution using a 12-bit ADC, and automatic shunt isolation for over-current protection.

ALT Image of the Erqos EQX2G quad-band GSM/GPRS expansion module mounted in a DIN-rail enclosure. The front panel shows the EQ logo, a prominent external antenna, status icons, a USB-C port, and a boot indicator. The module is designed to connect with the EQSP32 IoT Logic Controller to provide 2G cellular connectivity.

ALT DIN-rail assembly showing an EQSP32 IoT Logic Controller alongside Erqos expansion modules, including the EQXIO10 digital I/O module, EQXPT02 dual-channel RTD module, EQXTC06 thermocouple interface, and EQXPH01 pH meter. The modules are arranged in a row, illustrating the expandable architecture of the EQSP32 platform.

ALT EQSP32 Wireless IoT Controller demonstrating PCC (Pulse Capture Count) mode for super-high-speed pulse counting above 100 kHz in industrial automation. The image shows a stainless steel process pipe with a flow or pulse sensor connected to the EQSP32 Micro-PLC. The controller performs hardware-based pulse counting with selectable rising, falling, or toggle edge detection, up to four PCC channels active simultaneously, and frequency capture calculation using the EQTimer class. Ideal for flow metering, encoder feedback, and energy pulse monitoring in IIoT systems.

ALT The EQSP32 Library v1.0.x is here, bringing a major set of upgrades that make the EQSP32 Micro-PLC an even more powerful platform for automation. This release introduces long-awaited features including Ethernet connectivity (EQSP32CE) with automatic Wi-Fi/Ethernet switching and full support for OTA firmware updates. On the I/O side, the new library adds CIN (Current Input) 4–20 mA current loop support with built-in overcurrent protection, and a new PCC (Pulse Capture Counter) mode for precise measurement of pulse-based devices such as water flow meters, dosing pumps, and turbine sensors.
