Today I started developing the slab tool for #StructureTools #structuralengineering #structuralmodeling #grillage #spaceframes #structuralanalysis @FreeCADNews

I am pleased to announce that the #StructureTools workbench is now available for installation in the @FreeCADNews Addon Manager. #structuralengineering #structuralmodeling #spaceframes #structuralanalysis #AEC #BIM #StructureAnalysis #CivilEngineering #Structural #engine

Parametric model of metal beam joints using splints, used both to determine the stiffness of the connection through finite element analysis and for construction detailing. @FreeCADNews #structuralmodeling #structuralanalysis #AEC #StructureAnalysis #CivilEngineering #Structural

Static linear analysis performed with the #StructureTools workbench in @FreeCADNews . #civilconstruction #civil_engineering #civilengineer #civilengineeringstudent #civilengineerblog #civilengineeringdiscoveries #civilengineeringlife #civilengineering_life

What do you think of this type of automation? Should I continue developing tools of this type? #AEC #BIM #StructureAnalysis #FreeCAD #CivilEngineering #Structural #engine #StructureTools

Commercial project made with the StructureTools bench in @FreeCADNews , mezzanine with a free span of 10 m. #structuralengineering #structuralmodeling #spaceframes #structuralanalysis #AEC #BIM #StructureAnalysis #FreeCAD #CivilEngineering #Structural #engine #StructureTools

I was thinking about doing an official launch of the #StructureTools workbench, but on second thought I did it without seeing it, and it was an organic process, so if you haven't downloaded and installed it yet, feel free to do so, I'll leave the links below in the comments.

Continuing the development and improvement of structural analysis tools in @FreeCADNews #AEC #BIM #StructureAnalysis #FreeCAD #CivilEngineering #Structural #engineerin #StructureTools

#FreeCAD is gaining traction in the #AEC industry as a powerful, open source alternative for 3D modeling and design automation. Engineering, architecture, and construction with total freedom and customization. #BIM #StructureTools @FreeCADNews

StructureTools now calculates the self-weight of structural elements, and can also calculate truss elements. #BIM #StructureAnalysis #FreeCAD #CivilEngineering #Structural #engineerin

✅ Just wrapped up our live session on the new @StructureTools Workbench in #FreeCAD! We explored new structural workflows & analysis tools built right into FreeCAD. 🎥 Missed it? Watch the replay here: youtube.com/live/QIM8w1viFOw… #BIM #FOSS #StructuralEngineering

Soon, #StructureTools will enable engineers and designers to perform structural analysis in @FreeCADNews with free, intuitive tools, democratizing structural calculations. #BIM #StructureAnalysis #FreeCAD #CivilEngineering #Structural #engineerin

Thinking about the best way to convert solid objects from structural elements to bar elements, there are many specific cases in the fully automatic solution. #StructureTools #StructuralAnalysis #BIM #FreeCAD @FreeCADNews

🚨 Upcoming Live Alert! Join me this Sunday, 6th April at 9 PM IST for another #FreeCAD Live session. We’ll be diving into the upcoming #StructureTools Workbench — don’t miss it! 🔔 Set a reminder and see you there: youtube.com/live/QIM8w1viFOw… #StructuralAnalysis #BIM

What you are doing is very usefull! I did sometrhing simillar on Blender (not completed) to calculate beam parameters for the basement. The idea was to get it to web with ThreeJS

The first alpha version is almost ready to be released, and now we can see the value of our efforts. Let me know in the comments if you are looking forward to using StructureTools. @FreeCADNews
