After probably 100 hours I can finally say I am coming to a stop. Shout out to @Replit . This started for their 10 year anniversary buildathon and I haven't stopped since. Long days, sometimes 16 hour days at the weekend. I'm at a stage where I can finally sign off. KinetiCAD is browser-native parametric CAD. Real B-rep geometry kernel, OpenCascade compiled to WebAssembly. Live rigid-body physics with Rapier. Sketch, extrude, revolve, fillet, chamfer, boolean operations. Five mate types, motorised joints. An eight-material library with density-driven mass. STEP import, export and round-trip. WebGPU rendering. No install, no licence, no CAD seat. Verified by maths, not vibes: A motorised windmill assembly tuned to hold exactly pi radians per second. Across 420 simulation steps it held between 3.1415925 and 3.1415930. Target pi is 3.1415927. Every sample within 1.5e-7. Material mass is real arithmetic, not an estimate. A 5.70 cm³ part: steel at 7.87 g/cm³ gives 0.045 kg, brass at 8.50 gives 0.048 kg, PLA at 1.25 gives 0.007 kg. Exact, every time. If the maths is wrong, it is not a CAD tool. So the maths gets checked. FREE to use and open source. MIT licensed. I will always try something, even if I fail, because that's my mindset. kineticad.co.uk/ @ThreeJS #CAD #BuildInPublic #AdeviousAI

1/ I have just updated KinetiCAD: parametric CAD running entirely in a browser tab. Two engines in parallel Web Workers, a real B-rep kernel and a live physics engine. Full breakdown below. 2/ Geometry: OpenCascade, a real solid modelling kernel, compiled to WebAssembly. Sketching, Extrude, Revolve, Fillet, Chamfer, Hole, and Boolean operations (Union, Subtract, Intersect). Multi-part assemblies with a transform gizmo. 3/ Mates and physics: five mate types (Revolute, Prismatic, Spherical, Fixed, Planar), motors on revolute and prismatic joints. Rapier physics in a second worker turns the mates into real constraints and drives them. 4/ File interop: STL export, STEP import and export with full round-trip, plus native Save and Load of a whole assembly as JSON. STEP tested on real McMaster-Carr industrial parts. STL verified by slicing to a complete print plan in Bambu Studio. 5/ Proof it works: an orrery. 13 bodies, 12 motorised revolute joints in nested chains. Every build is regression-tested against a canary joint that must hold pi rad/s to within 5e-7. 6/ Before going public: a full audit. Secrets scan, static analysis, dependency check, no internal files leaking. All clean. WebGPU-only, built for modern hardware by design. Phases 0-9 of 12 done. Open source, MIT, live now: kineticad.replit.app/ github.com/AndrewBlumson/Kin… #BuildInPublic #CAD #AdeviousAI @threejs

Literally just make a new cheap geometry kernel. Or make OpenCASCADE better.

A new version of Open Cascade Technology 8.0 has been released. This geometric kernel forms the backbone of several projects such as #FreeCAD, #IfcOpenShell, or #KiCAD. The release announcement is here: occt3d.com/occt3d-open-sourc… #OpenCascade #OCCT3D #OCCT #OpenSource

💡 𝗢𝗽𝗲𝗻 𝗖𝗔𝗦𝗖𝗔𝗗𝗘 𝗧𝗲𝗰𝗵𝗻𝗼𝗹𝗼𝗴𝘆 𝟴.𝟬.𝟬 𝗶𝘀 𝗻𝗼𝘄 𝗮𝘃𝗮𝗶𝗹𝗮𝗯𝗹𝗲! Full release notes and discussion: github.com/Open-Cascade-SAS/… #OpenCASCADE #OCCT #OCCT3D #3DModeling #CAD #CAE #OpenSource #3D #Release
