After 16 weeks of RIGOROUS grind at
@Web3Bridge, participating in their Zero Knowledge program; My team built a full shielded token stack on EVM for private token transfers and I’m sharing both a demo video (Privacy native wallet extension User facing dApp UX) and the technical paper in this post.
Architecture: Noir circuit Barretenberg/Aztec UltraHonk proving Solidity verifier relayer client-side note discovery.
Model: UTXO-style notes with
- commitment = Poseidon(owner_pk, token_field, amount, blinding),
- Nullifier-based one-time spends (nullifier = Poseidon(spending_key, commitment)),
- Depth-20 incremental Merkle tree rolling root window, fixed public input lanes, and mode-gated constraints for transfer/unshield.
- ShieldedERC20Pool (multi-token allowlisted pool) with routed encrypted note delivery (RoutedCommitment) using ECDH HKDF-SHA256 AES-GCM, and channel/subchannel for note discovery.
Design goal is explicit: private in-pool state transitions with verifiable integrity, while shield/unshield remain honest public boundary actions.
If you watch the video read the paper, you’ll see both the privacy native wallet extension and the user facing dapp full loop working end-to-end: shield → private transfer(s) → note scan/decrypt → nullifier checks → unshield.
Big shout out to the mentors holding our hands throughout the duration of the program. The knowledge passed has been invaluable.
@WiseMrMusa,
@only1franchesco,
@Oba_Ddev,
@Dev_esayayo.
Next steps for us are;
- Production hardening and compliance-by-design
- Formal security review/audit of circuits/contracts/relayer, wallet key-management hardening (secure enclaves/HSM-backed options), relayer auth anti-replay protections
- Performance tuning for proof latency/UX.
- In parallel, we’ll implement a compliance layer that preserves base protocol privacy while enabling jurisdiction-aware controls at the app edge (sanctions/geo screening for boundary actions, risk scoring/transaction monitoring, optional disclosure and auditable consent flows for regulated contexts), alongside legal review and phased rollout with testnet pilots before mainnet.
Read technical document here:
drive.google.com/file/d/1oDq…
References / lineage:
(
@Zcash) Zcash protocol (UTXO commitments, nullifiers, shielded value flow)
(
@Ztark_Labs) STRK20 shielded token design direction
(
@aztecnetwork) Aztec/Barretenberg UltraHonk proving system
Noir language/tooling for circuit authoring.
